Strainless Steel Cable Ladder
The Stainless Steel Cable Ladder is a specialized type of cable management system designed to support, protect, and route electrical cables, wires, and hoses in demanding environments. It consists of two parallel side rails connected by round steel rungs at regular intervals, forming a ladder structure.
The strainless cable ladder construction from stainless steel (304 or 316). It gives it exceptional properties compared to standard steel or aluminum cable ladders.
As a leading manufacturer and supplier of cable trays, Bending offers high-quality cable tray solutions to meet a wide range of load capacities.
Strainless Steel Cable Ladder Features & Advantages
- Superior Corrosion Resistance: The primary advantage.
-
- Grade 304: Excellent resistance to a wide range of atmospheric, chemical, and food industry environments. Ideal for most indoor and many outdoor applications.
- Grade 316: Contains molybdenum, providing vastly enhanced resistance to chlorides and acidic compounds. The preferred choice for harsh environments like coastal/marine areas, chemical processing plants, pulp/paper mills, and water treatment facilities.
- High Strength & Durability: Stainless steel offers excellent mechanical strength and impact resistance, allowing for longer spans between supports and protecting cables from physical damage.
- Hygiene & Cleanability: It has a non-porous, smooth surface that is easy to clean and sterilize.
- Fire Resistance: Stainless steel is non-combustible and retains its structural integrity at very high temperatures, contributing to improved fire safety in buildings and industrial plants.
- Low Maintenance & Long Lifecycle: It does not require painting or galvanizing (like carbon steel) and is highly resistant to weathering and UV degradation. This results in minimal maintenance costs and a very long service life, offering excellent lifetime value.
- Aesthetic Appeal: It has a modern, clean, and professional appearance, making it suitable for visible installations in architectural projects, public spaces, or modern industrial facilities.
- Ventilation & Heat Dissipation: The open-ladder design allows for maximum airflow around cables, which helps dissipate heat generated by power cables, preventing overheating and improving system efficiency.
Strainless Steel Cable Ladder Structure
- Side Rails: The longitudinal beams that bear the load. Depth (height) determines stiffness and load capacity.
- Rungs: Cross-bars that provide cable support and retention spacing. Standard spacing is typically 225mm and 300mm.
- Fittings: A variety of components to create a complete pathway system:
- Straight Sections: Customizable.
- Tees and Crosses: For intersections.
- Reducers: To transition between different widths.
- Drops & Standoffs: To connect from the overhead ladder to cabinets/racks.
Strainless Steel Cable Ladder SPECS(mm)
| No. |
Width |
Height |
Rung Space |
Length |
| 1 |
200 |
100 |
225/300 |
2000 |
|
2
|
200 |
150 |
225/300 |
3000 |
| 3 |
300 |
100 |
225/300 |
2000 |
| 4 |
300 |
150 |
225/300 |
3000 |
| 5 |
400 |
100 |
225/300 |
3000 |
| 6 |
400 |
150 |
225/300 |
3000 |
| 7 |
500 |
100 |
225/300 |
2000 |
| 8 |
500 |
150 |
225/300 |
3000 |
| 9 |
600 |
100 |
225/300 |
2000 |
| 10 |
600 |
150 |
225/300 |
3000 |
| 11 |
700 |
100 |
225/300 |
2000 |
| 12 |
700 |
150 |
225/300 |
3000 |
Strainless Steel Cable Applications
Stainless steel cable ladders are used wherever durability, safety, and corrosion resistance are critical:
Industrial: Chemical plants, oil & gas platforms, offshore installations, mining, wastewater treatment plants, power generation.
Food & Beverage: Processing halls, breweries, dairies, abattoirs (where wash-down with corrosive cleaners is routine).
Marine & Coastal: Shipbuilding, ports, harbors, bridges, and any installation exposed to saltwater spray.
Pharmaceutical & Healthcare: Cleanrooms, production areas, laboratories.
Infrastructure: Transportation hubs (airports, train stations), tunnels, swimming pools.
Architectural: For visually exposed cable management in modern buildings, museums, or stadiums.
